| Lenght |
10M
|
|
Width
|
4,5M
|
| TOTAL height with Rails |
4,5M |
|
Transport height
|
3.7M
|
| Height from the water level |
4M |
|
Weight (aprox)
|
10.000kg
|
| Maximum number of passengers |
12 |
| Number of berths |
6 |
| Maximum boat engines power |
60 HP |
| Category |
"C" |
INTRODUCTION
Comfortable catamaran with the large residential space adapted for swimming on large lakes. Wide range of additional options allows to design interiors according to your needs. We recommend the installation of 2 outboard engines from Yamaha or Mercury. CE category project "C".
HULLS
We weld 4mm thick aluminum 5754 (model F or G) to produce high displacement and stiffness hulls. The size of the hull allows for placing large tanks and utilities in the openings. The float shape provides good nautical values, stability of the unit and batial stability.
CONSTRUCTION
Floors, walls and roofs are made of high quality polyester- glass laminates filled with polystyrene foam providing good thermal insulation. In every place required there are cable trays and plywood reinforcements. Special aluminum profiles are used for mounting.
STANDARD EQUIPMENT
- 40 HP hightrust Mercury outboard engine located in the middle of the transom
- Fuel tank 100l+gauge
- Clean water tank 420l+gauge
- Black water tank 420l +gauge
- Diesel tank 200l +gauge
- Underfloor heating and hot water - Diesel heating system
- Engine battery 65Ah
- Service battery 4x230Ah
- 230V port connector with 50A charger + Inwerter 3000W (Victron Multiplus), 6 sockets 230V inside the object
- Navigation and anchor lighting
- Outdoor LED lights
- Indoor LED lights
- Bluetooth radio +4 speakers
- Rear view camera with screen 7”
- 4 steps water ladder
- Interiors floors made of vinyl panels
- External floors of lower terraces made of durable composite deck
- Front/ rear railing, handrailing made of stainless steel
- Insulated windows and doors in aluminum frames with 2x4mm glazing. Tilt and turn windows and doors equipped with mosquito nets in aluminum frames.
- Sliding inner door (standard 40mm thick)
- Roller blinds in windows, custains in doors (color to choose)
- Stainless cleats 250mm x 6pcs.
- Set of lacquered kitchen furniture (RAL)
- Under-counter refrigerator, two-burner diesel stove and canopy, sink
- Sofa in the livingroom
- Master bedroom: bed 200x150cm, 2 cabinets ( in standard price 1 bedroom)
- Bathroom: equipped with shower 140x80cm, toilet, cabinet, washbasin, mirror
ADDITIONAL EQUIPMENT
|
5m wide (2 side terraces)- extra payment to the standard
|
4 220 €
|
|
Upper terrace ( the price include: utility upper terrace with deck made of composite deck)
|
9 240 €
|
|
Complete railing ( available only for 5m wide)
|
1 100 €
|
|
Steering console in the livingroom
|
460 €
|
|
Additional hight cabinet in the bathroom
|
660 €
|
|
Front side sliding window (only in the livingroom - price per piece)
|
790 €
|
|
Possibility to change the engine from 40HP to 60HP ( extra payment to the starndard price)
|
1 540 €
|
|
Possibility to change fuel tank from 100l to 200l
|
725 €
|
|
Bow thruster 185 mm
|
4 070 €
|
|
Stern thruster 185 mm
|
4 070 €
|
|
Electric anchor winch + chain + anchor
|
3 830 €
|
|
Solar package 8 x minimum 330W panels each
|
5 150 €
|
|
Sewage works and dirty water (Enteron 50)
|
12 650 €
|
|
Purification system to outboard water
|
6 780 €
|
|
Depth sounder with GPS 7”
|
2 180 €
|
|
Composite decking to the boat 5m wide
|
890 €
|
|
Additional lacquered aluminum locker (for outdoor use)
|
925 €
|
|
Connection to the washing machine (only available in bathroom B version)
|
330 €
|
|
Dishwasher 45cm with in-cabinet connection
|
1320 €
|
|
Electric bow searchlight
|
860 €
|
|
Painting hulls with polyurethane paint
|
3 830 €
|
|
Additional rear terrace ( depending on 1 or 2 engines)
|
2 380 €
|
|
Life saving and firefighting equipment (10 life jackets, wheel, 2 fire extinguishers)
|
860 €
|
|
Mooring equipment (2 x mooring rope, oar, boat hook, 4 x fender)
|
590 €
|
|
Changing the color of the external facade
|
1 050 €
|
